DZC系列垂直振动提升机
DZC系列振动提升机产品概述
DZC系列垂直振动提升机采用振动电机作振动源，利用两振动电机的合成振幅，将物料沿螺旋输送槽向上输送。DZC系列垂直振动提升机主要用于提升颗粒状、粉状、块状物料。本输送机结构简单,维修容易，物料定量送出，输送量连续可调，可作为各行业中,小颗粒物料的垂直输送之用.除具有从下向上提升物料外,还可以完成对物料的干燥、冷却作用。分开槽式、封闭式两种结构，并可根据不同工艺的要求，设计物料颗粒分级作用的筛选提升机及设计易燃易爆物料的提升机。
Product overview
DZC series vertical vibration hoist adopts vibration motor as vibration source, the use of two synthesis amplitude of vibration motor, the material along the spiral groove up transportation.DZC series vertical vibration of elevator is mainly used for granular, powder, block material.This machine has simple structure, easy maintenance, send the material quantitative, throughput continuous adjustable, can be used for various industries, small particle materials of vertical transportation. Besides has the material from the bottom up, also can complete drying, cooling effect of the material.Separate groove, and enclosed two kinds of structure, and can according to the requirements of different process, the design of material particle gradation selection hoist and hoist design inflammable and explosive materials.
碳钢材质垂直振动提升机
Corbon steel vertical vibrating elevator
不锈钢材质垂直振动提升机
stainless steel vertical vibrating elevator
DZC系列垂直振动提升机广泛应用于化工、橡胶、塑料、医药、轻工、食品、冶金、建材、矿山、粮食等行业。
DZC series vertical vibration of elevator is widely used in chemical industry, rubber, plastic, medicine, light industry, food, metallurgy, building materials, mining, food and other industries.
DZC系列振动提升机工作原理
DZC系列电机振动垂直提升机是由提升槽、振动电机、减振系统和底座等组成。该系列提升机是采用振动电机作为振动源，固定在提升槽上的两台相同型号的振动电机中心线交叉一定角度安装，并做相反方向自同步旋转，振动电机所带的偏心块在旋转时各个瞬间位置所产生的离心力之分力沿抛掷方向作往复运动，使支承在减振器上的整个机体不停振动，使物料在提升槽内被抛起的同时向上运动，物料落入入料槽后，开始被抛起，此时可以使物料与空气充分接触，还可以起到散热冷却的作用。该提升机对粉状、块状和短纤维状的固体物料（有粘性和易结块的除外）都可垂直输送，还可以完成对物料的干燥、冷却作用。分敞开式、封闭式两种结构。并可按照用户需要进行特殊设计。
Working site
DZC series vertical elevator is made up of improvement slot motor vibration, vibration motor, vibration isolation system and the base, etc.This series of hoist is the vibration motor as vibration source, on the improvement slot with two sets of the same type of the center line of the cross Angle vibration motor installation, and do the opposite direction from the synchronous rotation, vibration motor with eccentric block rotates at every instant position of the centrifugal force generated by the component along the casting direction for reciprocating motion, make the bearing on the shock absorber of whole body vibration, the material being thrown up in the improvement slot upward movement at the same time, the material fall into the trough, start being thrown up, this time can make a good contact with raw material and air, also can have the effect of thermal cooling.The elevator to the powder, block and short fibers of solid materials (except for a viscous and caked) can be vertical transmission, also can complete drying, cooling effect of the material.Open type, closed two structures.And we can special design according to user needs.
可根据客户要求，设计为振动电机上置
DZC系列垂直振动提升机视频
Animation ShownDZC系列振动提升机的型式
1.振动源分:
a.交叉轴式螺旋振动输送机。 b.平行轴式螺旋振动输送机。
2.以上两种又各自分为:
a.座式螺旋输送机。 b.悬挂式螺旋输送机。
The machine type
1. The vibration source points:
A. cross shaft spiral vibration conveyor.B. parallel shaft helical vibration conveyor.
2. The above two kinds of inductions are divided into:
A. a type screw conveyor.B. hanging screw conveyor.
DZC系列振动提升机主要特点
1.占地面积小、结构简单、合理。
2.动力消耗小、无噪音、维修方便。
3.封闭式提升有效的防止了粉尘和有害气体对工作环境的污染。
Features
1. The cover an area of an area small, simple structure, reasonable.
2. The little power consumption, no noise, easy maintenance.
3. Enclosed promote effectively prevent the dust and harmful gas pollution to the working environment.
DZC系列振动提升机型号说明
Models explanationDZ C □
┬ ┬ ┬
│ │ │
│ │ │
│ │ │
│ │ └───────────── 输送槽直径（mm）
│ │
│ └──────────────- 垂直
│
└──────────────── 电机振动
DZC型系列垂直振动提升机安装尺寸
Installation dimension
当DZC型系列垂直提升机工作时，根据双振动电机自同步原理，由振动电机产生激振力，强迫整个输送塔体作水平圆运动和向上垂直运动的空间复合振动，螺旋槽内的物料则受输送槽的作用，作匀速抛掷圆运动，沿输送槽体向上运动，从而完成物料的向上（或向下）输送作业。
When DZC series vertical hoist works, according to the principle of dual vibration motors self-synchronization, produced by the vibration motor excitation force, force the transmission tower body horizontal circular motion and vertical upward movement space complex vibration, material of spiral groove is the role of the conveying groove, a uniform circular motion, throwing down the conveyor tub upward movement, so as to complete material transport operation up (or down).
| 型号 | Φ | Φ1 | Φ2 | H | H1 | H2 | H3 | D | Lx8 | Ld×Bd | Φd |
|---|---|---|---|---|---|---|---|---|---|---|---|
| DZC300 | 300 | 146 | 500 | ～2000 | ～2750 | 40 | 75 | 270 | 680×680 | 11 | |
| DZC500 | 500 | 219 | 850 | ～3000 | ～4020 | 50 | 80 | 475 | 1080×1080 | 880×880 | 13 |
| DZC550 | 550 | 245 | 900 | ～3500 | ～4530 | 55 | 85 | 500 | 1100×1100 | 900×900 | 13 |
| DZC600 | 600 | 273 | 950 | ～4000 | ～5150 | 60 | 85 | 525 | 1100×1100 | 900×900 | 15 |
| DZC800 | 800 | 351 | 1200 | ～4500 | ～5650 | 60 | 90 | 650 | 1300×1300 | 1050×1050 | 15 |
| DZC850 | 850 | 402 | 1250 | ～5000 | ～6150 | 65 | 100 | 675 | 1400×1400 | 1150×1150 | 17 |
| DZC900 | 900 | 530 | 1300 | ～6000 | ～7180 | 65 | 110 | 700 | 1600×1600 | 1300×1300 | 17 |
DZC系列振动提升机技术参数表
Parameters
| 型号 | 输送量 (t/h) | 输送槽直径 (mm) | 输送宽度 (mm) | 输送高度 (m) | 振次 (min) | 双振幅 (mm) | 电动功率 (kw) | 重量 (kg) |
|---|---|---|---|---|---|---|---|---|
| DZC300 | ～1.0 | 300 | 77 | ≤2.0 | 960 | 6～7 | 2×0.4 | 680 |
| DZC500 | ～2.0 | 500 | 140 | ≤3.0 | 6～8 | 2×0.75 | 1010 | |
| DZC550 | ～3.0 | 550 | 152 | ≤3.5 | 6～8 | 2×1.5 | 1190 | |
| DZC600 | ～3.0 | 600 | 163 | ≤4.0 | 6～7 | 2×1.5 | 1321 | |
| DZC800 | ～4.0 | 800 | 224 | ≤4.5 | 6～8 | 2×2.2 | 1590 | |
| DZC850 | ～4.0 | 850 | 224 | ≤5.0 | 6～9 | 2×2.2 | 1750 | |
| DZC900 | ～3.5 | 900 | 185 | ≤6.0 | 6～9 | 2×3.0 | 2100 |
